The XB5SSoft is a freeware application and can be downloaded from our website www.schneider-electric.com. The user database cannot be uploaded from USB biometric switch to the PC. Compatible with Magelis iPC, STU, OT, GXO, GT (except GT1000 series), GK, GH, and GTO models. Below are the steps to change the name of M258 controller from USB memory stick. 1 SoMachine Menu Online /USB mass storage include com.
Interface Description
Schneider Electric Port Devices Driver Download Free
IGSS offers an interface for the Modicon PLC series and Modbus compatible systems using the Serial Modbus RTU and ASCII protocols.
The communication driver uses standard RS-232 serial ports to connect to up to 8 PLCs. Each of these PLCs may in turn be connected to other devices (e.g. other PLCs) via a separate network (e.g. Modbus or Modbus Plus networks)
The communication interface supports both direct and dial-up connections.
The IGSS system polls the PLC equipment cyclically according to one of four user-defined time intervals. The time intervals are configurable from 100 milliseconds to 999 seconds. The system automatically groups process data in data blocks – thus fully exploiting the communication link in relation to the present configuration.
Technical Data
Schneider Electric Port Devices Driver Download Windows 7
| Electrical Interface | : | RS-232 point-to-point connection |
| Protocol | : | Modbus RTU/ASCII |
| Types of data | : | String, Fixed point 8, 16, 32, BCD 16, 32, Floating Point etc. |
| PLC types supported | : | All PLCs supporting AEG Modicon Modbus RTU/ASCII protocol. E.g. Milltronics Enviroranger ERS 500, GRUNDFOS CU401 Controller |
| Addressing | : | Node (PLC), data type (Coils, Discrete Input, Word Inputs, and Holding Registers), offset , bit offset (a whole number of words is read or written) |
| Supported platforms | : | Windows Vista, Windows XP, Windows 2003 Server, Windows 2000 |
| Max. telegram size | : | Up to 250 bytes per telegram |
| Transmission speed | : | Up to 115 Kbaud depending on the PLC port speed |
| Throughput | : | 3-4 telegrams per PLC per second (depending on baudrate) |
| Max. number of channels | : | Up to 8 connections are supported concurrently |
| PC hardware requirements | : | 1-8 standard serial ports (COM ports). Standard modem(s) if dialled-up connections are used |
| PC software requirements | : | None |
